Edge - material removal method: Using the principle of scissors cutting, the blade angle is 2°. It uses a high - definition vision system to ensure positioning accuracy, and is equipped with a servo adjustment system. The position is automatically adjusted according to the product.
Vacuum handling, product side - thickness measurement, product pre - positioning, quick change of suction cups, automatic identification of suction cups, product grabbing and material separation, automatic vacuum switching, maximum size: 225*225mm, automatic tool alignment, equipped with a vacuum dust - removal mechanism, automatic switching of product size, no - material alarm, quick adjustment of size, maximum lifting stroke is 230mm.
Equipment Dimensions: 1500*1200*1800 (length * width * height)
A. Properly wear protective equipment.
B. Conduct equipment safety inspections.
C. Follow operating procedures and risk mitigation measures:
Do not touch moving parts (e.g., cutters, pulley wheels) with hands.
Do not adjust, measure, or clean debris by hand during operation.
For multi-person collaborative operations, clarify division of responsibilities to avoid accidental activation of control devices.
D. Equipment maintenance and emergency preparedness:
Perform regular maintenance and upkeep.
Clean equipment after use; inspect worn parts (e.g., cutters, bearings) and replace them promptly.
Regularly test safety devices (e.g., protective covers, emergency stop switches); unauthorized removal is prohibited.
E. Emergency response:
In case of sudden malfunction or accident, immediately cut off power and report the incident; do not attempt to repair equipment while it is running.
Delivery period: 90 days.
